Camera | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Sensor | 1/2.8" CMOS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pixel | 2 MP | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Resolution | 1920 (H) × 1080 (V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ROM | 4 GB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RAM | 1 GB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Shutter Speed | 1/1 s–1/30,000 s | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Scanning System | Progressive | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Min. Illumination | Color: 0.005 [email protected] | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illumination Distance | 150 m (492.13 ft) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illuminator On/Off Control | Zoom Prio; Manual; Smart IR; Off | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Illuminator Number | 4 (IR) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focal Length | 3.95 mm–177.75 mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. Aperture | F1.6–F4.95 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Field of View | H:65.7°–1.9°V:39.4°–1.1°D:73.1°–2.1° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Optical Zoom | 45× | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focus Control | Auto; semi-auto; manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Close Focus Distance | 0.1 m–1 m (0.33 ft–3.28 ft) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Iris Control | Auto; manual | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DORI Distance | Detect | Observe | Recognize | Identify | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
2451.7 m (8043.64 ft) | 972.9 m (3191.93 ft) | 490.3 m (1608.60 ft) | 245.2 m (804.46 ft) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PTZ | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
