| DONANIM ÖZELLİKLERİ | |
|---|---|
| Standartlar ve Protokoller | IEEE 802.3i / 802.3u / 802.3ab/ 802.3x /802.1p |
| Arabirim | 8× 10/100/1000Mbps Ports, Auto-Negotiation, Auto-MDI/MDIX |
| Fan Sayısı | Fanless |
| Harici Güç Kaynağı | External Power Adapter (Output: 5 V DC / 0.6 A) |
| LED | • Power • Link/Act indicators per port built into each RJ-45 port |
| Boyutlar ( W X D X H ) | 6.2 x 4.0 x 1.0 in. (158 x 101 x 25 mm) |
| Maks. Güç Tüketimi | 3.92 W(220 V /50 Hz) |
| Max Heat Dissipation | 13.37 BTU/h |
| PERFORMANS | |
|---|---|
| Paket Yönlendirme Hızı | 11.9 Mpps |
| MAC Adres Tablosu | 4K |
| Paket Buffer Belleği | 1.5 Mb |
| Jumbo Frame | 16 KB |
| YAZILIM ÖZELLİKLERİ | |
|---|---|
| Gelişmiş Özellikler | • Green Ethernet technology • 802.3X Flow Control • 802.1p/DSCP QoS • IGMP Snooping • Loop Prevention |
| İletim Metodu | Store and Forward |
| DİĞERLERİ | |
|---|---|
| Sertifika | CE, FCC ,RoHS |
| Paket İçeriği | • DS108G • Power Adapter • Installation Guide |
| Ortam | • Operating Temperature: 0°C~40°C (32°F~104°F) • Storage Temperature: -40°C~70°C (-40°F~158°F) • Operating Humidity: 10% ~ 90%, non-condensing • Storage Humidity: 5%~90% non-condensing |
